LED lighting cooling solution-60MMseries big/small gob

With the rising demand of environmental protection and energy saving in various countries, LED lighting has long life, power saving, environmental protection and other characteristics, and the key problems need to be solved become the mainstream industry of the market However, in the LED high Ming power development, how to effectively heat, become LED lighting urgent In the LED light parts, the power supply parts are easy to cause early damage due to the local temperature，Generally, when the ambient temperature of electronic components, such as electrolytic capacitor, increases by 10℃, the life will be reduced by half, and conversely, if reduced by 10℃, the life will be doubled. Shenzhen LFKZ LED lighting cooling solution-60MMseries big/small gob combined with the flow channel design can guide the air flow to the power supply parts, to reduce the temperature of the internal parts, improve the service life of LED lights.

Send Inquiry

Product Description

With the rising demand of environmental protection and energy saving in various countries, LED lighting has long life, power saving, environmental protection and other characteristics, and the key problems need to be solved become the mainstream industry of the market

However, in the LED high Ming power development, how to effectively heat, become LED lighting urgent In the LED light parts, the power supply parts are easy to cause early damage due to the local temperature，Generally, when the ambient temperature of electronic components, such as electrolytic capacitor, increases by 10℃, the life will be reduced by half, and conversely, if reduced by 10℃, the life will be doubled.

Shenzhen LFKZ LED lighting cooling solution-60MMseries big/small gob combined with the flow channel design can guide the air flow to the power supply parts, to reduce the temperature of the internal parts, improve the service life of LED lights.

Size:606015mm

1. 94V-0fire prevention、ROHS2.0 Environmental materials

1. Optional automatic restart, back contact protection、FG、RD、PWM function

product property :

Insulation impedance :DC500V Maug meter measurement，10MQ以上

Insulation and pressure resistance :AC500V 1min

insulation grade : Class B

Tolerance of the ambient temperature range:

Working :-10℃~+70℃ (hydraulic bearing ) -20℃~+80℃(ball bearing )

normal temperature :-20°℃~+75°℃ (hydraulic bearing)

Product material:

Epitheca :PBT plastic (black)UL94V-0

hypotheca:PBT plastic (black)UL94V-0

Impeller :PBT plastic (black)UL94V-0

Bearing :ball bearing、hydraulic pressure bearing-40℃~+85°C(ball)

Wire:UL1061 AWG26 red:+ black

Expected:

50000 hours（ball bearing)

30000 hours (hydraulic pressure bearing)

2. 94V-0 fire protection, ROHS 2.0 environmental protection material

2. Optional automatic restart, reverse contact protection, FG, RD, PWM functions

3. Insulation level: ClassB

compliant:

Purifier, LED and other industries

Rated voltage	Voltage range	Rotational speed	Electric current	power	Air volume		Wind pressure		noise	curve	weight
VDC	VDC	RPM	A	W	CFM	M3/h	mmH₂O	nchH₂O	dBA	colour	g
24	12~26.4	6000	0.20	4.80	7.00	11.89	31.62	1.25	51.7	black	32
		5000	0.12	2.88	6.20	10.53	23.21	0.91	44.3	red
		4000	0.05	1.20	4.52	7.68	13.16	0.52	37.5	green
		3000	0.03	0.72	3.28	5.57	5.06	0.20	30.2	blue
12	6~14	6000	0.35	4.20	7.00	11.89	31.62	1.25	51.7	black
		5000	0.25	3.00	6.20	10.53	23.21	0.91	44.3	red
		4000	0.12	1.44	4.52	7.68	13.16	0.52	37.5	green
		3000	0.06	0.72	3.28	5.57	5.06	0.20	30.2	blue
